Wastewater & drain pipe insulation

PAROC® wastewater & drain pipe insulation
Prevent condensation and noise

If cold rainwater from the roof is routed through the building, the pipes have to be insulated to prevent the warm indoor air from condensing on the pipes. Similarly, wastewater pipes also need to be insulated against condensation and, depending on local regulations, against fire and noise. A reduced sound level guarantees a more pleasant sound environment for the building occupants.

To avoid the risk of condensation, the quality of the installation is crucial. For optimum results, the installation needs to be sealed and without any holes in the cladding, with all joints carefully taped. We therefore offer special tapes for a tight installation.

Insulation with a reinforced aluminium foil, on a wastewater pipe

Benefit from drain and wastewater pipe insulation

Prevent condensation

Indoor rainwater and wastewater pipes that run from the roof through the property are often colder than the surrounding air in the building, which increases the risk of condensation.

The factors that determine whether water vapour condensation forms on the pipe are the surface temperature of the pipe, the ambient air temperature, and relative humidity. To prevent condensation on the insulation surface, the pipe needs to be insulated so that the surface temperature of the insulation is higher than the dew point of the surrounding air.

To minimise the risk of condensation and vapour permeability, PAROC® products have a water vapour-resistant barrier in the form of a reinforced aluminium foil called AluCoat. This in combination with PAROC® tape can enable an easy and correct installation with precise joint seals. No additional gluing is needed.

Avoid fire hazards

When tested to EN 13501-1, PAROC® products offer the highest fire class either Euroclass A1 or A2-s1,d0. Our stone wool insulation products are non-combustible. They do not burn or contribute to fire spread. They will not produce any smoke or very limited amount of smoke, nor do they produce flaming droplets. The softening temperature of stone wool products is *over 1000°C. The fire performance of stone wool does not deteriorate with high temperatures, nor with time. The surface temperature of faced products must not exceed 80°C.

*Owens Corning internal test results, June 2023-24 for normal quality control/FPC.

Quick installation

With a length of 1.2m, PAROC® Hvac Sections make installation quick and help to reduce the number of joints and potential thermal bridges, when comparing to the 1.0m insulation solutions. PAROC® Hvac Sections also have a self-adhesive overlap and in combination with a suitable tape make installation easy.

Avoid disturbing noise

Wastewater pipes are only used occasionally and therefore need to be insulated to minimise disturbing noises. The stone wool structure provides excellent sound insulating properties that helps to ensure quiet and comfortable indoor conditions.

Products

Filters

Filter

Product Type

Insulation(2)

Insulation Type

Bend or segment(1)
Pipe section(1)

PAROC Hvac Bend AluCoat T

PAROC Hvac Bend AluCoat T is a pre-fabricated pipe insulation bend made of non-combustible PAROC® stone wool. The product is designed to provide thermal and condensation insulation for pipework. The pre-fabricated PAROC Hvac Bend Alucoat T makes for faster and easier installation with the potential of minimizing waste...

PAROC Hvac Section AluCoat T

PAROC Hvac Section AluCoat T is a pipe section for pipe insulation made of non-combustible PAROC® stone wool. The product is designed to provide thermal and condensation insulation for pipework. It is suitable for indoor and outdoor pipes and can withstand medium temperatures of up to 250 °C. For outdoor installations...

Certificates and Declarations

CE

M1

BREEAM

EUCEB

LEED

BES 6001

Our PAROC insulation solutions are certified with CE and may help your project qualify for BREEAM or LEED, enabling you to build to high standards. To help you make informed decisions, all our product declarations, DoP and EPDs, are made available on our website. We can also supply you with additional mandatory and voluntary certifications related to responsible sourcing, emissions and safety, such as BES 6001, M1, Blue Angel, and Nordic Swan.

Certificate Search

PAROC Calculus

PAROC Calculus is a technical insulation calculation program for dimensioning thermal insulation for various applications in the HVAC and Process industries.
